Tauri、React、Node.js、GridDB によるデスクトップ WiFi ネットワーク・モニターの構築

git clone git@github.com:junwatu/bearsakura-netwatch.git

cd server
npm install

npm install -g node-gyp

PACKET_PORT=5000
DATABASE_SERVER_PORT=4000

npm run dev

cd server-db
npm install

DATABASE_SERVER_PORT=4000

npm run dev

{
    "api": {
        "base_url": "http://localhost:4000"
    }
}

node --version

import pkg from 'cap';
const { Cap, decoders } = pkg;

const PROTOCOL = decoders.PROTOCOL;

let packets = [];

function startCapturing(ipAddress) {
    const c = new Cap();
    const device = Cap.findDevice(ipAddress);
    const filter = 'ip';
    const bufSize = 10 * 1024 * 1024;
    const buffer = Buffer.alloc(65535);

    const devices = Cap.deviceList();
    const wifiDevice = devices.find(device => {
        const description = device.description.toLowerCase();
        return description.includes('wireless') || description.includes('wi-fi');
    });

    if (!wifiDevice) {
        console.error('No Wi-Fi device found!');
        process.exit(1);
    }

    const wifiInterfaceName = wifiDevice.name;
    const linkType = c.open(wifiInterfaceName, filter, bufSize, buffer);

    c.on('packet', function(nbytes, trunc) {
        const ret = decoders.Ethernet(buffer);

        if (ret.info.type === 2048) {
            const decodedIP = decoders.IPV4(buffer, ret.offset);
            const srcaddr = decodedIP.info.srcaddr;
            const dstaddr = decodedIP.info.dstaddr;

            let packetInfo = {
                length: nbytes,
                srcaddr: srcaddr,
                dstaddr: dstaddr
            };

            if (decodedIP.info.protocol === PROTOCOL.IP.TCP) {
                const decodedTCP = decoders.TCP(buffer, decodedIP.offset);
                packetInfo.protocol = 'TCP';
                packetInfo.srcport = decodedTCP.info.srcport;
                packetInfo.dstport = decodedTCP.info.dstport;
            } else if (decodedIP.info.protocol === PROTOCOL.IP.UDP) {
                const decodedUDP = decoders.UDP(buffer, decodedIP.offset);
                packetInfo.protocol = 'UDP';
                packetInfo.srcport = decodedUDP.info.srcport;
                packetInfo.dstport = decodedUDP.info.dstport;
            }

            packets.push(packetInfo);

            // Limit the storage to the last 100 entries (or any other number)
            if (packets.length > 100) packets.shift();
        }
    });
}

function getPackets() {
    return packets;
}

export { startCapturing, getPackets };

import 'dotenv/config';
import express from 'express';
import bodyParser from 'body-parser';
import axios from 'axios';
import * as packetCapturer from './packetCapturer.js';

const app = express();
app.use(bodyParser.json());

const PORT = process.env.PACKET_PORT || 3000;
const HOST = process.env.PACKET_IP_ADDRESS || 'localhost';
const SERVER_DB_HOST = process.env.DATABASE_SERVER || 'localhost';
const SERVER_DB_PORT = process.env.DATABASE_SERVER_PORT || 4000;

packetCapturer.startCapturing(process.env.PACKET_IP_ADDRESS);

setInterval(async () => {
    const packets = packetCapturer.getPackets();
    try {
        await axios.post(`http://${SERVER_DB_HOST}:${SERVER_DB_PORT}/save-packets`, packets);
        console.log('Packets sent successfully');
    } catch (error) {
        console.error('Error sending packets:', error);
    }
}, 5000);  // Adjust the interval to your needs


app.get('/packets', (req, res) => {
    res.json(packetCapturer.getPackets());
});

app.listen(PORT, HOST, () => {
    console.log(`Server started on http://${HOST}:${PORT}`);
});

import 'dotenv/config';
import cors from 'cors';
import express from 'express';
import bodyParser from 'body-parser';
import* as griddb from './griddbservice.js'

const app = express();
app.use(cors());
app.use(bodyParser.json());

const PORT = process.env.DATABASE_SERVER_PORT || 4000;
const HOST = process.env.DATABASE_SERVER || 'localhost';

app.get(
    '/info', (req, res) = > { res.json({message : 'database server'}); });

app.post(
    '/save-packets', async(req, res) = > {
      const packets = req.body;

      for (let packet of packets) {
        const {length, srcaddr, dstaddr, protocol, srcport, dstport} = packet;
        await griddb.saveData(
            {length, srcaddr, dstaddr, protocol, srcport, dstport});
      }

      res.json({message : 'saved'});
    });

app.get('/get-all-packets', async (req, res) => {
  const packets = await griddb.getAllData();
  res.json({packets});
})

app.listen(PORT, HOST, () => {
    console.log(`Server started on http://${HOST}:${PORT}`);
});

await griddb.saveData({length, srcaddr, dstaddr, protocol, srcport, dstport});

app.get('/get-all-packets', async (req, res) => {
  const packets = await griddb.getAllData();
  res.json({packets});
})

import React, { useState, useEffect } from 'react'
import PacketVisualization from './packet-visualization'
import { invoke } from "@tauri-apps/api/tauri";

import "./App.css";

function App() {
  const [packetData, setPacketData] = useState(null)
  const [apiBaseUrl, setApiBaseUrl] = useState(null)

  useEffect(() => {
    async function fetchPacketData() {
      const config = await invoke('read_config');
      const apiBaseUrlConfig = await invoke('get_api_base_url', { config: config });
      const response = await fetch(`${apiBaseUrlConfig}/get-all-packets`)
      const data = await response.json()

      setPacketData(data)
      setApiBaseUrl(apiBaseUrlConfig)
    }

    fetchPacketData()

    // fetch every 5 seconds
    const intervalId = setInterval(fetchPacketData, 5000)
    // cleanup interval on component unmount
    return () => clearInterval(intervalId)
  }, [])


  return (
    <div className="container">
      {packetData && <packetvisualization data={packetData}></packetvisualization>}
      <p className='packet-server'>
        Packet Server: {apiBaseUrl}
      </p>
    </div>
  );
}

export default App;

const config = await invoke('read_config');
const apiBaseUrlConfig = await invoke('get_api_base_url', { config: config });
const response = await fetch(`${apiBaseUrlConfig}/get-all-packets`)

{
    "api": {
        "base_url": "http://localhost:4000"
    }
}

// Prevents additional console window on Windows in release, DO NOT REMOVE!!
#![cfg_attr(not(debug_assertions), windows_subsystem = "windows")]

use std::fs;
use serde_json::Value;

// Learn more about Tauri commands at https://tauri.app/v1/guides/features/command
#[tauri::command]
fn greet(name: &str) -> String {
    format!("Hello, {}! You've been greeted from Rust!", name)
}

#[tauri::command]
fn read_config() -> Result<String, String> {
  let path = "config.json";
  let config = fs::read_to_string(path).map_err(|e| e.to_string())?;
  Ok(config)
}

#[tauri::command]
fn get_api_base_url(config: String) -> Result<String, String> {
  let parsed_config: Value = serde_json::from_str(&config).map_err(|e| e.to_string())?;
  let base_url = parsed_config
    .get("api")
    .and_then(|api| api.get("base_url"))
    .and_then(|base_url| base_url.as_str())
    .ok_or("Missing 'api.base_url' setting")?;
  Ok(base_url.to_string())
}

fn main() {
    tauri::Builder::default()
        .invoke_handler(tauri::generate_handler![greet, read_config, get_api_base_url])
        .run(tauri::generate_context!())
        .expect("error while running tauri application");
}
