In the most recent release of GridDB CE (version 5.3), a new SQL function was added that allows a user to fetch interpolated or aggregated data for a set of time ranges over a total duration from a TIMESERIES container. We explored similar functionality before in this blog post GridDB Optimization with Multi-Put and Query by building a set of queries to query each individual group and then efficiently executing them with GridDB’s multi-query function.

The new query function is quite simple:

SELECT * FROM table WHERE ts_col > TIMESTAMP(start) and ts_col <= TIMESTAMP(end) GROUP BY RANGE (n, duration)

In the above example, ts_col is is the index of the time-series container. The start and end variables are the starting and ending timestamps of the data queried and the query must have those clauses. Finally, each group’s duration is n*duration. The duration can be:

DAY
HOUR
MINUTE
SECOND
MILLISECOND

You can also query an aggregate of each time group such as the MIN, MAX, AVG, COUNT, SUM, etc.

SELECT ts_col,AVG(value) FROM table WHERE ts_col > TIMESTAMP(start) and ts_col <= TIMESTAMP(end) GROUP BY RANGE (n, duration)

Finally, if your data is sparse, the non-aggregate query’s interpolation can be adjusted by appending FILL(method) to the end of the query. Available fill methods include:

LINEAR
NONE
NULL
PREVIOUS

Hands On¶

Now, let’s get started trying it out. We’ll use the already ingested dataset from GridDB’s 101 Course https://www.youtube.com/playlist?list=PLZiizI6Euect9q64akYBkiqLMS78UTwjO. Dataset can be found here on Kaggle. Code for ingestion can be found on the GitHub page (it's written in node.js.)

As this is a SQL function, it is only available via GridDB’s JDBC or WebAPI interface. In this blog we’ll be using the Python module jpype.dbapi2 as it natively supports SQL and the Timestamp to Python datetime object conversion. Compare the following two outputs using jaydebe and jpype.dbapi2: jaydebe outputs a string while jype.dbapi2 outputs a datetime object.

In [2]:

import jaydebeapi

jdbeurl = "jdbc:gs://127.0.0.1:20001/myCluster/public"
jdbeconn = jaydebeapi.connect("com.toshiba.mwcloud.gs.sql.Driver", jdbeurl, ["admin", "admin"], "./lib/gridstore-jdbc.jar")

jdbecurs = jdbeconn.cursor()
jdbecurs.execute("SELECT ts FROM device2 limit 1")
rows = jdbecurs.fetchall()
print(type(rows[0][0]), rows[0][0])

<class 'str'> 2020-07-11 17:01:34.735000

In [3]:

import jpype
import jpype.dbapi2

url = "jdbc:gs://127.0.0.1:20001/myCluster/public"
conn = jpype.dbapi2.connect(url, driver="com.toshiba.mwcloud.gs.sql.Driver", driver_args={"user": "admin", "password": "admin"})

curs = conn.cursor()
curs.execute("SELECT ts FROM device2 limit 1")
rows = curs.fetchall()
print(type(rows[0][0]), rows[0][0])

<class 'datetime.datetime'> 2020-07-11 17:01:34.735000

With the connection setup we can create a function that gets the first and last timestamps and build the group by range query. The function itself returns data as Pandas DataFrame with the columns set to match the table columns.

In [4]:

import datetime
import pandas as pd

def getRange(conn, table, range):
    curs = conn.cursor()
    curs.execute("SELECT min(ts),max(ts) from "+table)
    rows = curs.fetchall()
    start = rows[0][0];
    end = rows[0][1]

    curs.execute("""select * from """+table+""" where ts >= TO_TIMESTAMP_MS("""+str(int(start.timestamp()*1000))+""")
                 and ts <= TO_TIMESTAMP_MS("""+str(int(end.timestamp()*1000))+""") group by range (ts) EVERY (1, """+range+""");""");

    cols = tuple(zip(*curs.description))[0]
    df = pd.DataFrame(curs.fetchall(), columns=cols)
    return df

def getAll(conn, table):
    curs = conn.cursor()

    curs.execute("""select * from """+table);

    cols = tuple(zip(*curs.description))[0]
    df = pd.DataFrame(curs.fetchall(), columns=cols)
    return df

getRange(conn, "device2", "DAY")

Out[4]:

	ts	co	humidity	light	lpg	motion	smoke	temp
0	2020-07-11 17:00:00	0.002840	76.000000	False	0.005114	False	0.013275	19.700001
1	2020-07-12 17:00:00	0.011738	73.900002	False	0.014276	False	0.039740	18.900000
2	2020-07-13 17:00:00	0.004167	74.300003	False	0.006749	False	0.017851	19.000000
3	2020-07-14 17:00:00	0.004577	73.699997	False	0.007222	False	0.019193	18.900000
4	2020-07-15 17:00:00	0.008437	73.599998	False	0.011243	False	0.030792	18.700001
5	2020-07-16 17:00:00	0.002350	74.800003	False	0.004459	False	0.011467	19.700001
6	2020-07-17 17:00:00	0.004816	76.500000	False	0.007494	False	0.019964	18.900000
7	2020-07-18 17:00:00	0.004878	77.099998	False	0.007563	False	0.020162	19.200001
8	2020-07-19 17:00:00	0.003700	75.599998	False	0.006193	False	0.016285	19.299999

Now let’s try an aggregate query:

In [5]:

def getAggregates(conn, table, agg, column, range):
    curs = conn.cursor()
    curs.execute("SELECT min(ts),max(ts) from "+table)
    rows = curs.fetchall()
    start = rows[0][0];
    end=rows[0][1]

    curs.execute("""select ts,"""+agg+"("+column+") from "+table+" where ts >= TO_TIMESTAMP_MS("+str(int(start.timestamp()*1000))+""")
                 and ts <= TO_TIMESTAMP_MS("""+str(int(end.timestamp()*1000))+") group by range (ts) EVERY (1, "+range+");");

    df = pd.DataFrame(curs.fetchall(), columns=("ts", column))
    return df

getAggregates(conn, "device2", "min", "humidity", "DAY")

Out[5]:

	ts	humidity
0	2020-07-11 17:00:00	21.600000
1	2020-07-12 17:00:00	22.900000
2	2020-07-13 17:00:00	22.100000
3	2020-07-14 17:00:00	22.100000
4	2020-07-15 17:00:00	21.400000
5	2020-07-16 17:00:00	23.799999
6	2020-07-17 17:00:00	24.299999
7	2020-07-18 17:00:00	1.100000
8	2020-07-19 17:00:00	75.300003

If you have a boolean column that represents an event and want to see that happened in each time grouping, you can use the MAX aggregation:

In [6]:

getAggregates(conn, "device2", "max", "motion", "DAY")

Out[6]:

	ts	motion
0	2020-07-11 17:00:00	False
1	2020-07-12 17:00:00	False
2	2020-07-13 17:00:00	False
3	2020-07-14 17:00:00	False
4	2020-07-15 17:00:00	True
5	2020-07-16 17:00:00	False
6	2020-07-17 17:00:00	False
7	2020-07-18 17:00:00	True
8	2020-07-19 17:00:00	False

To count the number of events (or the number times a column is TRUE) in each time window, you need to add an additional clause AND column to your query:

In [7]:

def getBoolCount(conn, table, column, range):
    curs = conn.cursor()
    curs.execute("SELECT min(ts),max(ts) from "+table)
    rows = curs.fetchall()
    start = rows[0][0];
    end=rows[0][1]

    curs.execute("select ts,count("+column+") from "+table+" where ts >= TO_TIMESTAMP_MS("+str(int(start.timestamp()*1000))+""")
                  and ts <= TO_TIMESTAMP_MS("""+str(int(end.timestamp()*1000))+") and "+column+" group by range (ts) EVERY (1, "+range+");");

    df = pd.DataFrame(curs.fetchall(), columns=("ts", column))
    return df

getBoolCount(conn, "device2", "motion", "DAY")

Out[7]:

	ts	motion
0	2020-07-11 17:00:00	NaN
1	2020-07-12 17:00:00	NaN
2	2020-07-13 17:00:00	NaN
3	2020-07-14 17:00:00	NaN
4	2020-07-15 17:00:00	2.0
5	2020-07-16 17:00:00	NaN
6	2020-07-17 17:00:00	NaN
7	2020-07-18 17:00:00	1.0
8	2020-07-19 17:00:00	NaN

Now that we know how to use the group by range aggregate function, we can build some diagrams that show useful statistics such as a bar chart showing the min and max values of each time group.

First since group by range is typically used to down sample data, lets compare every data point stored versus a daily interpolation:

In [8]:

getAll(conn, "device2")

Out[8]:

	ts	co	humidity	light	lpg	motion	smoke	temp
0	2020-07-11 17:01:34.735	0.002840	76.000000	False	0.005114	False	0.013275	19.700001
1	2020-07-11 17:01:46.869	0.002938	76.000000	False	0.005241	False	0.013628	19.700001
2	2020-07-11 17:02:02.785	0.002905	75.800003	False	0.005199	False	0.013509	19.700001
3	2020-07-11 17:02:11.476	0.002938	75.800003	False	0.005241	False	0.013628	19.700001
4	2020-07-11 17:02:15.289	0.002840	76.000000	False	0.005114	False	0.013275	19.700001
...	...	...	...	...	...	...	...	...
111810	2020-07-19 17:03:16.329	0.003745	75.300003	False	0.006247	False	0.016437	19.200001
111811	2020-07-19 17:03:20.684	0.003745	75.400002	False	0.006247	False	0.016437	19.200001
111812	2020-07-19 17:03:25.039	0.003745	75.400002	False	0.006247	False	0.016437	19.200001
111813	2020-07-19 17:03:33.162	0.003745	75.300003	False	0.006247	False	0.016437	19.200001
111814	2020-07-19 17:03:36.979	0.003745	75.300003	False	0.006247	False	0.016437	19.200001

111815 rows × 8 columns

Getting all rows (above) results in 111815 rows with each row approximately 5-30 seconds appart. Using group by range to down sample to hourly results in only 193 rows.

In [15]:

getRange(conn, "device2", "HOUR")

Out[15]:

	ts	co	humidity	light	lpg	motion	smoke	temp
0	2020-07-11 17:00:00	0.002840	76.000000	False	0.005114	False	0.013275	19.700001
1	2020-07-11 18:00:00	0.002528	75.599998	False	0.004701	False	0.012133	19.600000
2	2020-07-11 19:00:00	0.002375	76.300003	False	0.004494	False	0.011562	19.700001
3	2020-07-11 20:00:00	0.002395	76.300003	False	0.004520	False	0.011635	19.700001
4	2020-07-11 21:00:00	0.002613	74.699997	False	0.004815	False	0.012445	19.500000
...	...	...	...	...	...	...	...	...
188	2020-07-19 13:00:00	0.002613	77.000000	False	0.004815	False	0.012445	19.600000
189	2020-07-19 14:00:00	0.003049	75.199997	False	0.005384	False	0.014023	19.600000
190	2020-07-19 15:00:00	0.003230	75.400002	False	0.005613	False	0.014662	19.200001
191	2020-07-19 16:00:00	0.003570	75.699997	False	0.006034	False	0.015840	19.299999
192	2020-07-19 17:00:00	0.003700	75.599998	False	0.006193	False	0.016285	19.299999

193 rows × 8 columns

Now lets plot the same two data sets:

In [16]:

import matplotlib.pyplot as plt

day = getRange(conn, "device2", "HOUR")
all = getAll(conn, "device2")

plt.plot(all['ts'],  all['humidity'], label='All Data Points', color='blue')
plt.plot(day['ts'],  day['humidity'], label='Daily Interpolation', color='orange')
plt.xticks(rotation = 45);
plt.ylabel('Humidity')
plt.legend(loc="lower left");

Now we visualize daily minimums and maximums:

In [10]:

mins = getAggregates(conn, "device2", "min", "humidity", "DAY")
maxes = getAggregates(conn, "device2", "max", "humidity", "DAY")

plt.bar(mins['ts'], maxes["humidity"]-mins["humidity"], bottom=mins["humidity"]);
plt.xticks(rotation = 45);

We can expand on the above graph by adding data from the interpolated values too. Note how the interpolated value (red) is slightly different from the AVG aggregate (yellow).

In [11]:

mins = getAggregates(conn, "device2", "min", "humidity", "DAY")
maxes = getAggregates(conn, "device2", "max", "humidity", "DAY")
avgs = getAggregates(conn, "device2", "avg", "humidity", "DAY")
all = getRange(conn, "device2", "DAY")

plt.bar(mins['ts'], maxes["humidity"]-mins["humidity"], bottom=mins["humidity"], color='blue')
plt.scatter(x=avgs['ts'], y=avgs['humidity'], color='yellow', marker='_')
plt.scatter(x=all['ts'], y=all['humidity'], color='red', marker='_')
plt.xticks(rotation = 45);
plt.ylabel('Humidity', color='blue')

plt2 = plt.twinx()
plt2.plot(all['ts'],  all['temp'], color='orange')
plt2.set_ylabel('Temperature', color='orange');

Finally, group by range can also interpolate values between data points with the FILL function. This is useful if data is sparse or at random intervals and you want to build a table. You can see the missing intervals without using fill and how FILL(PREVIOUS) continues to use the last value until a new value is met while FILL(LINEAR) interpolates the values between data points.

In [12]:

def getRangeFilled(conn, table, range, fill):
    curs = conn.cursor()
    curs.execute("SELECT min(ts),max(ts) from "+table)
    rows = curs.fetchall()
    start = rows[0][0];
    end = rows[0][1]

    curs.execute("""select * from """+table+""" where ts >= TO_TIMESTAMP_MS("""+str(int(start.timestamp()*1000))+""")
                 and ts <= TO_TIMESTAMP_MS("""+str(int(end.timestamp()*1000))+""") group by range (ts) EVERY (1, """+range+""")
                 FILL("""+fill+""");""");

    cols = tuple(zip(*curs.description))[0]
    df = pd.DataFrame(curs.fetchall(), columns=cols)
    return df

prev = getRangeFilled(conn, "subdevice2", "MINUTE", "PREVIOUS").head(10)
nofill = getRange(conn, "subdevice2", "MINUTE").head(10)
linear = getRangeFilled(conn, "subdevice2", "MINUTE", "LINEAR").head(10)
all = getAll(conn, "subdevice2").head(10)

df = pd.DataFrame()
df.index = nofill.index
df['no_fill'] = nofill['humidity']
df['prev_fill'] = prev['humidity']
df['linear_fill'] = linear['humidity']
df

Out[12]:

	no_fill	prev_fill	linear_fill
0	75.199997	75.199997	75.199997
1	NaN	75.199997	75.033330
2	NaN	75.199997	74.866664
3	74.699997	74.699997	74.699997
4	NaN	74.699997	74.765214
5	NaN	74.699997	74.830432
6	NaN	74.699997	74.895649
7	NaN	74.699997	74.960867
8	NaN	74.699997	75.026084
9	NaN	74.699997	75.091301

Visualizing the above data shows the concept even more clearly with the FILL(PREVIOUS) plot nearly matching the lines drawn by MatPlotLib between unfilled points:

In [13]:

last = getRangeFilled(conn, "subdevice2", "MINUTE", "PREVIOUS").head(140)
filled = getRangeFilled(conn, "subdevice2", "MINUTE", "LINEAR").head(140)
all = getAll(conn, "subdevice2").head(10)

plt.plot(filled['ts'],  filled['humidity'], label='Linear Fill', color='red')
plt.plot(last['ts'],  last['humidity'], label='Previous Value Fill', color='green')
plt.plot(all['ts'],  all['humidity'], label='All Data Points', color='blue')

plt.xticks(rotation = 45);
plt.ylabel('Humidity')
plt.legend(loc="lower right");

If you’d like to experiment with the group by range function, the above Jupyter notebook can be downloaded from GridDB.net’s GitHub repository here https://github.com/griddbnet/Blogs/blob/group_by_range/group_by_range.ipynb.
