Time Bucketing with GridDB

You’ve ingested a set of timeseries data into GridDB and want to see aggregates across individual time periods (also called windows or buckets) within the data set? GridDB’s TIME_SAMPLING function allows you to perform time weighted averages but what about counts or the minimum or maximum values in each time period? For example, you want to find the maximum value of a column every day or the number of samples every hour. GridDB’s multi-query function along with your programming language’s time, date, and calendar functions allows you to do just that.

In this blog, we’ll cover not only using GridDB’s TIME_SAMPLE TQL function but also build a generic function that can fetch multiple aggregates from the NYC Taxi Data data set.

Here is the specific file. We are downloading this file into your /tmp directory because the ingest code is hard-coded to read from there. If you would like to download to another location, please make sure you also change the file path in the src/main/java/net/griddb/tstaxiblog/IngestParquet.java code.

$ wget -O /tmp/yellow_tripdata_2021-01.parquet https://d37ci6vzurychx.cloudfront.net/trip-data/yellow_tripdata_2021-01.parquet

Prerequisites

To follow along with this project, you will need to download and install GridDB: https://docs.griddb.net/latest/gettingstarted/using-apt/#install-with-deb

You will also need to be able to use GridDB with java. To do so: https://docs.griddb.net/latest/gettingstarted/java/

Ingest Data in Parquet Format

In our past NYC Taxi Data blog, the data was available as a CSV which is easy to parse. Now, the NY Taxi Commission releases the data in Parquet format which has its advantages but is more difficult to parse.

First, we need to include the many libraries required to use the Apache Parquet Library: parqet-avro, parqet-hadoop, parqet-format, hadoop-common, hadoop-client. Since we’re using Maven, we add the following to our dependencies:

<dependency>
    <groupId>org.apache.parquet</groupId>
    <artifactId>parquet-hadoop</artifactId>
    <version>1.9.0</version>
</dependency>
<dependency>
    <groupId>org.apache.parquet</groupId>
    <artifactId>parquet-format</artifactId>
    <version>2.9.0</version>
</dependency>
<dependency>
    <groupId>org.apache.parquet</groupId>
    <artifactId>parquet-avro</artifactId>
        <version>1.9.0</version>
</dependency>
<dependency>
  <groupId>org.apache.hadoop</groupId>
  <artifactId>hadoop-common</artifactId>
  <version>2.10.0</version>
</dependency>
<dependency>
    <groupId>org.apache.hadoop</groupId>
    <artifactId>hadoop-client</artifactId>
    <version>2.10.1</version>
    <scope>provided</scope>
</dependency>

Now in our Java source we can read the parquet file and iterate through its groups of rows.

Path path = new Path("yellow_tripdata_2021-01.parquet");
Configuration conf = new Configuration();

try {
    ParquetMetadata readFooter = ParquetFileReader.readFooter(conf, path, ParquetMetadataConverter.NO_FILTER);
    MessageType schema = readFooter.getFileMetaData().getSchema();
    ParquetFileReader r = new ParquetFileReader(conf, path, readFooter);

    PageReadStore pages = null;
    try {
        while (null != (pages = r.readNextRowGroup())) {
            final long rows = pages.getRowCount();
            System.out.println("Number of rows: " + rows);

            final MessageColumnIO columnIO = new ColumnIOFactory().getColumnIO(schema);
            final RecordReader recordReader = columnIO.getRecordReader(pages, new GroupRecordConverter(schema));
            for (int i = 0; i < rows; i++) {
                final Group g = (Group)recordReader.read();
                writeGroup(ts, g);

            }
        }
    } finally {
        r.close();
    }
} catch (IOException e) {
    System.out.println("Error reading parquet file.");
    e.printStackTrace();
}

The writeGroup function is called for each group of rows and actually does the writing and populates and writes an instance of our TaxiTrip class with the data in each row.

private static void writeGroup(TimeSeries ts, Group g) throws GSException {

    int fieldCount = g.getType().getFieldCount();
    int valueCount = g.getFieldRepetitionCount(0);
    for (int index = 0; index < valueCount; index++) {
        TaxiTrip r = new TaxiTrip();
        for (int field = 0; field < fieldCount; field++) {

            try {
            Type fieldType = g.getType().getType(field);
            String fieldName = fieldType.getName();

            if (fieldType.isPrimitive()) {
                switch(fieldName) {
                    case "tpep_pickup_datetime":
                        r.tpep_pickup_datetime = new Date(g.getLong(field, index)/1000);
                        break;
                    /* .... snip ... */
                    case "fare_amount":
                        r.fare_amount = (float)g.getDouble(field, index);
                        break;
                    /* .... snip .... */
                    default:
                        System.out.println("Unknown field: "+fieldName+" value="+g.getValueToString(field, index));
                }
            }
            } catch (Exception e) {
            }
        }
        ts.put(r);
    }
}

GridDB’s TIME_SAMPLING Function

GridDB’s TIME_SAMPLING function returns a linear interpolation of the column values within each window. It has the following function signature:

TIME_SAMPLING(column, start, end, window_count, window_size)

The function works by finding the interpolation of for each request timestamp by using the rows before and after it. The following graphic visualizes the concept.

More details can be found in the GridDB programming guide.

The code simply executes the query and iterates through each window returned.

public static void timeSampling(GridStore store, String column, Date start, Date end, String windowstr) throws GSException {

    TimeZone tz = TimeZone.getTimeZone("UTC");
    DateFormat df = new SimpleDateFormat("yyyy-MM-dd'T'HH:mm:00'Z'");
    df.setTimeZone(tz);

    Container ts = store.getContainer("NYC_TaxiTrips");
    String querystr = "select time_sampling("+column+", TIMESTAMP('"+df.format(start)+"'), TIMESTAMP('"+df.format(end) +"') , 1, "+windowstr+") ";

    Query<row> q = ts.query(querystr);
    RowSet</row><row> rs = q.fetch();
    while (rs.hasNext()) {
        Row result = rs.next();
        System.out.println(result.getTimestamp(0)+"="+result.getDouble(10));
    }

}</row>

Calling timeSampling(store, "fare_amount", start, end, "DAY"); results in the following values:

Window Sample
Fri Jan 01 00:00:00 GMT 2021 14.833333015441895
Sat Jan 02 00:00:00 GMT 2021 8.55555534362793
Sun Jan 03 00:00:00 GMT 2021 15.710000038146973
Mon Jan 04 00:00:00 GMT 2021 25.31818199157715
Tue Jan 05 00:00:00 GMT 2021 22.024999618530273
Wed Jan 06 00:00:00 GMT 2021 9.0
Thu Jan 07 00:00:00 GMT 2021 43.5
Fri Jan 08 00:00:00 GMT 2021 6.0
Sat Jan 09 00:00:00 GMT 2021 28.950000762939453
Sun Jan 10 00:00:00 GMT 2021 18.450000762939453
Mon Jan 11 00:00:00 GMT 2021 41.75
Tue Jan 12 00:00:00 GMT 2021 6.5
Wed Jan 13 00:00:00 GMT 2021 17.710525512695312
Thu Jan 14 00:00:00 GMT 2021 10.8125
Fri Jan 15 00:00:00 GMT 2021 52.0
Sat Jan 16 00:00:00 GMT 2021 28.200000762939453
Sun Jan 17 00:00:00 GMT 2021 9.977272987365723
Mon Jan 18 00:00:00 GMT 2021 9.100000381469727
Tue Jan 19 00:00:00 GMT 2021 25.66666603088379
Wed Jan 20 00:00:00 GMT 2021 34.349998474121094
Thu Jan 21 00:00:00 GMT 2021 5.5
Fri Jan 22 00:00:00 GMT 2021 7.472727298736572
Sat Jan 23 00:00:00 GMT 2021 10.5
Sun Jan 24 00:00:00 GMT 2021 17.0
Mon Jan 25 00:00:00 GMT 2021 21.0
Tue Jan 26 00:00:00 GMT 2021 15.852941513061523
Wed Jan 27 00:00:00 GMT 2021 7.984375
Thu Jan 28 00:00:00 GMT 2021 42.83333206176758
Fri Jan 29 00:00:00 GMT 2021 9.083333015441895
Sat Jan 30 00:00:00 GMT 2021 11.892857551574707
Sun Jan 31 00:00:00 GMT 2021 14.371428489685059

While TIME_SAMPLING is useful, it has has some limitations since it only returns a linear interpolation for each window, each of which is typically similar to the average value (like medians are similar) but is not a true average. Likewise, you can’t find the number of rows in the time window or the minimum or maximum values.

Windowed Aggregations with Multi-Query

To find any aggregation for a set of timeseries windows, we can use GridDB’s multi-query function. This runs the specified aggregation for each time window separately. The following graphic shows the queries for each window:

You might think performing the operations like this would be slow, but by using multi-query we can optimize sending the queries to GridDB and the data retrieval. The database performs the same operations as it would if the function were built-in.

The first steps in our generic windowed aggregation function is to open the container and create a query for each window and add it to the list of queries that will be executed by GridDB. Each query is built by using Java’s Calendar class and incrementing the interval by the specified Calendar ENUM value such as Calendar.HOUR or Calendar.DATE.

public static void windowAggregation(GridStore store, String aggregation, Date start, Date end, int windowsize) throws GSException {
    Calendar c = Calendar.getInstance();
    ArrayList<Query<aggregationresult>> queryList = new ArrayList<Query</aggregationresult><aggregationresult>>();
    ArrayList<date> dates = new ArrayList</date><date>();
    Container ts = store.getContainer("NYC_TaxiTrips");

    c.setTime(start);
    Date interval = c.getTime();

    do {
        c.add(windowsize, 1);
        System.out.println("interval="+interval);
        String windowquery = "select "+aggregation+" where tpep_pickup_datetime > TO_TIMESTAMP_MS("+interval.getTime()+") and tpep_pickup_datetime < TO_TIMESTAMP_MS("+c.getTime().getTime()+")";
        Query<aggregationresult> q = ts.query(windowquery, AggregationResult.class);
        dates.add(interval);
        queryList.add(q);
        interval = c.getTime();
    } while (interval.getTime() <= end.getTime());
</aggregationresult></date></aggregationresult>

After we have our list of queries, we can execute them and iterate through the results.

    store.fetchAll(queryList);

    for (int i = 0; i < queryList.size(); i++) {
        Query<aggregationresult> query = queryList.get(i);
        RowSet</aggregationresult><aggregationresult> rs = query.getRowSet();
        while (rs.hasNext()) {
            AggregationResult result = rs.next();
            double value = result.getDouble();
            if (value != 0)
                System.out.println(dates.get(i)+"= "+ value);
        }
    }


}
</aggregationresult>

Calling windowAggregate(store, "avg(fare_amount)", start, end, Calendar.DATE); results in the following results:

Window avg(fare_amount)
Fri Jan 01 00:00:00 GMT 2021 13.851391098873778
Sat Jan 02 00:00:00 GMT 2021 13.770499047323876
Sun Jan 03 00:00:00 GMT 2021 15.249551398785178
Mon Jan 04 00:00:00 GMT 2021 13.473628681590766
Tue Jan 05 00:00:00 GMT 2021 12.676972567160476
Wed Jan 06 00:00:00 GMT 2021 12.243332028212064
Thu Jan 07 00:00:00 GMT 2021 12.464050631310585
Fri Jan 08 00:00:00 GMT 2021 12.091422930601727
Sat Jan 09 00:00:00 GMT 2021 12.537748556275371
Sun Jan 10 00:00:00 GMT 2021 13.496787364093032
Mon Jan 11 00:00:00 GMT 2021 12.350597800281259
Tue Jan 12 00:00:00 GMT 2021 12.189052448708432
Wed Jan 13 00:00:00 GMT 2021 11.970959482137403
Thu Jan 14 00:00:00 GMT 2021 12.338237139653735
Fri Jan 15 00:00:00 GMT 2021 12.24978189382601
Sat Jan 16 00:00:00 GMT 2021 12.348960280360648
Sun Jan 17 00:00:00 GMT 2021 12.987822185285506
Mon Jan 18 00:00:00 GMT 2021 12.66304436182826
Tue Jan 19 00:00:00 GMT 2021 12.19362357336725
Wed Jan 20 00:00:00 GMT 2021 11.760170207452589
Thu Jan 21 00:00:00 GMT 2021 12.153647415269047
Fri Jan 22 00:00:00 GMT 2021 12.026541242751565
Sat Jan 23 00:00:00 GMT 2021 11.73361113486781
Sun Jan 24 00:00:00 GMT 2021 12.876742517934895
Mon Jan 25 00:00:00 GMT 2021 12.229045667216711
Tue Jan 26 00:00:00 GMT 2021 11.716670845330835
Wed Jan 27 00:00:00 GMT 2021 11.823579132291002
Thu Jan 28 00:00:00 GMT 2021 11.842199614451049
Fri Jan 29 00:00:00 GMT 2021 11.784085302551507
Sat Jan 30 00:00:00 GMT 2021 11.843539460445053
Sun Jan 31 00:00:00 GMT 2021 12.406643581985854

We can also see the number of rows by calling windowAggregate(store, "count(*)", start, end, Calendar.DATE):

Window COUNT(*)
Fri Jan 01 00:00:00 GMT 2021 20430.0
Sat Jan 02 00:00:00 GMT 2021 25429.0
Sun Jan 03 00:00:00 GMT 2021 20909.0
Mon Jan 04 00:00:00 GMT 2021 30733.0
Tue Jan 05 00:00:00 GMT 2021 31667.0
Wed Jan 06 00:00:00 GMT 2021 32965.0
Thu Jan 07 00:00:00 GMT 2021 33306.0
Fri Jan 08 00:00:00 GMT 2021 33628.0
Sat Jan 09 00:00:00 GMT 2021 28626.0
Sun Jan 10 00:00:00 GMT 2021 23034.0
Mon Jan 11 00:00:00 GMT 2021 31583.0
Tue Jan 12 00:00:00 GMT 2021 33201.0
Wed Jan 13 00:00:00 GMT 2021 33633.0
Thu Jan 14 00:00:00 GMT 2021 34580.0
Fri Jan 15 00:00:00 GMT 2021 34706.0
Sat Jan 16 00:00:00 GMT 2021 28094.0
Sun Jan 17 00:00:00 GMT 2021 24373.0
Mon Jan 18 00:00:00 GMT 2021 26830.0
Tue Jan 19 00:00:00 GMT 2021 33525.0
Wed Jan 20 00:00:00 GMT 2021 32902.0
Thu Jan 21 00:00:00 GMT 2021 34652.0
Fri Jan 22 00:00:00 GMT 2021 35478.0
Sat Jan 23 00:00:00 GMT 2021 29830.0
Sun Jan 24 00:00:00 GMT 2021 23776.0
Mon Jan 25 00:00:00 GMT 2021 32064.0
Tue Jan 26 00:00:00 GMT 2021 31969.0
Wed Jan 27 00:00:00 GMT 2021 34148.0
Thu Jan 28 00:00:00 GMT 2021 35670.0
Fri Jan 29 00:00:00 GMT 2021 35219.0
Sat Jan 30 00:00:00 GMT 2021 28349.0
Sun Jan 31 00:00:00 GMT 2021 23674.0

If you wanted to run the window query daily to get hourly aggregates, you could set up a cronjob or loop the program with a sleep():

Calendar c = Calendar.getInstance();
Date now = new Date();
Date start = c.add(Calendar.DATE, -1).getTIme();
c.add(windowsize, 1);
windowAggregate(store, "avg(*)", start, now, Calendar.HOUR);

Conclusion

As shown, it’s easy to perform time window aggregation with GridDB. The complete source code for this blog can be found on GridDB.net’s GitHub page here.

git clone --branch time-bucketing https://github.com/griddbnet/Blogs.git

To run this project, you can use maven; first to ingest:

mvn package exec:java -Dexec.mainClass="net.griddb.tstaxiblog.IngestParquet"

After ingest completes, it will show the number of taxi trips ingested or errors that it couldn’t find the parquet file. It is also normal to see this error caused by the Parquet Libraries:

java.lang.InterruptedException
    at java.lang.Object.wait(Native Method)
    at java.lang.ref.ReferenceQueue.remove(ReferenceQueue.java:144)
    at java.lang.ref.ReferenceQueue.remove(ReferenceQueue.java:165)
    at org.apache.hadoop.fs.FileSystem$Statistics$StatisticsDataReferenceCleaner.run(FileSystem.java:3693)
    at java.lang.Thread.run(Thread.java:748)

You can use gs_sh and TQL “select count(*) NYC_TaxiTrips” to confirm the data was ingested properly.

And then to run the analysis:

mvn package exec:java -Dexec.mainClass="net.griddb.tstaxiblog.TaxiQuery"

If you have any questions about the blog, please create a Stack Overflow post here https://stackoverflow.com/questions/ask?tags=griddb .
Make sure that you use the “griddb” tag so our engineers can quickly reply to your questions.
